Westermo L106-F2G
Endüstriyel Layer2 Yönetilebilir 6 Port Fiber Ethernet Switch ( 4×10/100-TX + 2×100/1000 Mbit SFP ( FX/TX ) )
Genel Özelliklerinden Bazıları;
Kompakt Endüstriyel Ethernet Switch Dizaynı
- 4 adet 10/100 Mbps TX + 2 adet Gbit SFP slot ( 100/1000 Mbps FX veya 1 Gbit TX )
- Esnek SFP Transceiver seçenekleri ( 1 Gbit TX, 100/1000 Mbit FX, BiDi )
- 120 Km ‘ye kadar Fiber bağlantı desteği
- Gelişmiş WeOS Layer 2 fonksiyonları
- Düşük enerji tüketimi
Endüstriyel Uygulama Kullanımı İçin Tasarlanmıştır
- Yedekli 19 – 60 VDC enerji beslemesi
- Konfigüre edilebilir hata I/O kontağı
- Metal Kaplama, DIN Ray montajlı, IP 40 Koruma Sınıf
Uzun Servis Ömrü İçin Dayanıklılık
- MTBF = 499,000 saat ( MIL-HDBK-217K)
- Geniş çalışma sıcaklık aralığı -40 dan +70 °C
- Endüstriyel elektromagnetik (EMC), Şok ve titreşim testlerine sahip
Gelecek İhtiyaçlarıda Karşılayan Endüstriyel Network Çözümleri
- Seri IP dönüşüm ( Legacy IP Conversion )
- Uzak erişim ve Network IP security
- Birden çok esnek ağ çözümü
Uluslar Arası Onay Sertifikalarından Bazıları
- DNV Standart, Marine
- EN 50121-4 / IEC 62236-4 , Railway Trackside
- UL / IEC / EN 60950-1 , Safety
- ABB Industrial IT Enabled
Fiyat, teknik detaylar veya kullanım alanlarıyla ilgili bilgi talebiniz için bizimle irtibata geçebilirsiniz.
General data
|
|
| Type |
19 inch Fanless Rackmount IPC |
| Series |
Rugged Substation Automation PC |
| Supported Operating Systems |
Microsoft Windows 10 IoT Enterprise 2021, Microsoft Windows Server Standard 2022, LF Energy SEAPATH pre-installation, Linux Ubuntu Desktop 22.04 LTS, Linux Debian 12 Desktop pre-installation , Linux Ubuntu Server 22.04 LTS, Linux Debian 12 Server pre-installation , VMware® ESXi® 8.0, Red Hat Enterprise Linux 9, Red Hat Enterprise Linux 9 for Real Time |
CPU 1
|
|
| CPU |
Intel Xeon W-11865MLE with 8 Cores |
| Generation |
Tiger Lake, 11. Generation |
| Available till |
2035 |
| Frequency / Frequency max. |
1.5/4.5 GHz |
| Cores / Threads |
8/16 |
| L3 cache |
24 MB |
| Passmark CPU Perfomance |
~16.000 |
CPU 2
|
|
| CPU |
Intel Xeon W-11555MLE with 6 Cores |
| Generation |
Tiger Lake, 11. Generation |
| Available till |
2035 |
| Frequency / Frequency max. |
1.9/4.4 GHz |
| Cores / Threads |
6/12 |
| L3 cache |
12 MB |
| Passmark CPU Perfomance |
~11.900 |
Memory / RAM
|
|
| Socket type |
4x SO-DIMM 1,2 V |
| Storage type |
3200MHz DDR4 |
| Capacity |
max. 128 GB |
Chipset
Mass storage
|
|
| m.2 Socket |
1x M.2 2280 NVMe up to 1TB |
| Internal Drive Bay |
4x 2.5 inch SATA HDD/SSD Hot Swappable Bay up to 4TB |
| SATA Controller |
Intel RM590E SATA Controller provides standard AHCI and Intel VMD RAID Modes |
| Interface for Bays |
SATA III 6.0 Gbit/s |
| RAID |
RAID Level 0, 1, 5, 10 – Windows based OS only |
Graphics
|
|
| Graphic chip (GPU) |
Intel® UHD Graphics for 11th Gen Intel® Processors |
| Direct X Level |
Level 12.1 |
| OpenGL |
4.6 |
| Displays |
3x Display Port 4096 x 2304@60Hz |
Interfaces & Features
|
|
| USB |
5x USB 3.0 (4x rear, 1x front with key lock) + 1x internal USB 3.0 onboard Type A |
| PCIe Expansion |
1x PCIe x16 slot, full lenght, low profile / 3x PCIe x4 slot, full length, low profile |
| Serial Ports |
2x RS-232/422/485 (DB9 with isolation) |
| Ethernet |
8x RJ45 10/100/1000/2500 MBit copper ports, Intel® Ethernet Controller I226-IT |
| Real-Time Clock/Calendar |
3V 230mA PANASONIC CR2032L-JP-W-1A |
| BIOS |
AMI UEFI |
| Trusted Platform Module |
SLM9670AQ2.0 TPM2.0 |
Power supply
|
|
| Power supply |
2x slots for power supply unit modules |
Physical characteristics
|
|
| Housing color |
Pantone® Gray 446 |
| Dimensions (W x H x D) |
438 x 88 x 302 mm |
| Ingress protection |
IP20 |
| Weight |
8500 g |
| Mounting |
19″ Rack |
Environmental
|
|
| Operating temperature range |
-40 to +70 °C |
| Storage temperature range |
-40 to +85 °C |
| Humidity |
5 % to 95 % @ 40 °C |
| Insulation Class |
Class 1 |
Approvals
|
|
| CE |
Yes |
| FCC |
Yes |
| RoHS |
Yes |
| UL/cUL |
Yes |
| IEC 61850-3 |
Yes |
| IEEE 1613 |
Yes |
| CB |
Yes |
| ICES |
Yes |
| REACH |
Yes |
